‌Mistral OCR 是一款由欧洲 AI 公司 Mistral 发布的光学字符识别（OCR）API，号称“世界上最好的 OCR 模型”。‌

主要特点

1. ‌顶尖的复杂文档理解能力‌：

   • Mistral OCR 能够准确识别和理解文档中的各种元素，包括媒体、文本、表格、公式等。
   • 擅长处理复杂的文档结构，如交错的图像、数学表达式、表格以及 LaTeX 等高级排版格式。
   • 能够深入理解包含图表、图形、公式和插图的科学论文等复杂文档。

2. ‌原生多语言和多模态支持‌：

   • 支持全球数千种语言、字体及文字系统，具备出色的多语言能力。
   • 能够处理多种模态的内容，包括图像、文本、表格等。

3. ‌顶级的基准测试表现‌：

   • 在多项基准测试中，Mistral OCR 的表现均优于其他领先的 OCR 模型。
   • 在总体准确率、数学公式识别、多语言处理等方面均表现出色。

4. ‌极致处理速度‌：

   • Mistral OCR 的处理速度远超同类模型，单节点每分钟可处理高达 2000 页文档。
   • 快速处理文档的能力确保了即使在高吞吐量环境下也能持续学习和改进。

5. ‌“文档即提示”的结构化输出‌：

   • Mistral OCR 创新性地引入了“文档即提示”的概念，用户可以使用文档作为提示，实现更强大、更精确的指令。
   • 允许用户从文档中提取特定信息，并将其格式化为 JSON 等结构化输出，便于下游功能调用与智能体开发。

6. ‌安全部署选项‌：

   • 对于有严格数据隐私要求的组织，Mistral OCR 提供自托管选项，确保敏感或机密信息安全。

应用场景

• ‌科学研究数字化‌：顶尖研究机构使用 Mistral OCR 将科学论文和期刊转化为 AI 就绪格式，便于下游智能引擎使用，显著加快协作速度并加速科学工作流程。
• ‌历史文化遗产保护‌：组织和非营利机构使用 Mistral OCR 对历史文献和文物进行数字化，确保其得以保存，并让更多人能够接触到。
• ‌客户服务流程优化‌：客户服务部门借助 Mistral OCR 将文档和手册整理为便于检索的知识库，从而缩短响应时间，提升客户满意度。
• ‌跨行业智能化‌：适用于教育课件、法律文件、工程图纸等专业内容的 AI 就绪化处理，释放数百万文档中的智慧，提高生产力。

使用方式

• ‌网页端试用‌：用户可以通过 Mistral 的官方网站免费试用 Mistral OCR 的基础功能。
• ‌API 调用‌：开发者可以通过 Mistral 的开发者平台 la Plateforme 调用 Mistral OCR 的 API，实现更高级的功能。API 定价为每 1000 页 1 美元，批量处理时效率翻倍。

性能对比

与 Google Document AI、Azure OCR 等主流 OCR 产品相比，Mistral OCR 在总体准确率、数学公式识别、多语言处理等方面均表现出色。尤其在处理复杂文档和多模态内容时，Mistral OCR 的优势更加明显。

Mistral OCR

功能强大的光学字符识别服务

• 处理 PDF、图像和其他文档格式
• 保留文档结构和格式
• 处理多页文档
• 识别表格、列表和其他复杂元素

Mistral Embeddings

• 将文本转换为数字表示：
• 将文本转换为 1024 维向量
• 捕捉概念之间的语义关系
• 实现基于意义的相似性匹配
• 为语义搜索奠定基础

Milvus 向量数据库

用于向量相似性搜索的专用数据库：

• 开源
• 执行高效的向量搜索
• 可扩展至大型文档 Collections
• 支持混合搜索（向量相似性 + 元数据过滤）
• 针对人工智能应用进行了优化

本教程结束时，您将拥有一个可以实现以下功能的系统

1. 通过 URL 处理文档（PDF/图片
2. 使用 OCR 提取文本
3. 将文本和向量嵌入存储在 Milvus 中
4. 在文档 Collections 中执行语义搜索

---

设置和依赖

首先，让我们安装所需的软件包：

$ pip install mistralai pymilvus python-dotenv

环境设置

你需要

1. 一个 Mistral API 密钥（从 https://console.mistral.ai/ 获取一个）
2. 通过Docker或Zilliz Cloud在本地运行 Milvus

让我们来设置环境：

import json
import os
import re

from dotenv import load_dotenv
from mistralai import Mistral
from pymilvus import CollectionSchema, DataType, FieldSchema, MilvusClient
from pymilvus.client.types import LoadState

# Load environment variables from .env file
load_dotenv()

# Initialize clients
api_key = os.getenv("MISTRAL_API_KEY")
if not api_key:
    api_key = input("Enter your Mistral API key: ")
    os.environ["MISTRAL_API_KEY"] = api_key

client = Mistral(api_key=api_key)

# Define models
text_model = "mistral-small-latest"  # For chat interactions
ocr_model = "mistral-ocr-latest"  # For OCR processing
embedding_model = "mistral-embed"  # For generating embeddings

# Connect to Milvus (default: localhost)
milvus_uri = os.getenv("MILVUS_URI", "http://localhost:19530")
milvus_client = MilvusClient(uri=milvus_uri)

# Milvus collection name
COLLECTION_NAME = "document_ocr"

print(f"Connected to Mistral API and Milvus at {milvus_uri}")

Connected to Mistral API and Milvus at http://localhost:19530

设置 Milvus Collections

现在，让我们创建一个 Milvus Collection 来存储我们的文档数据。Collections 将包含以下字段：

• id:主键（自动生成）
• url:文档的源 URL
• page_num:文件的页码
• content:提取的文本内容
• embedding:内容的向量表示（1024 维）

def setup_milvus_collection():
    """Create Milvus collection if it doesn't exist."""
    # Check if collection already exists
    if milvus_client.has_collection(COLLECTION_NAME):
        print(f"Collection '{COLLECTION_NAME}' already exists.")
        return

    # Define collection schema
    fields = [
        FieldSchema(name="id", dtype=DataType.INT64, is_primary=True, auto_id=True),
        FieldSchema(name="url", dtype=DataType.VARCHAR, max_length=500),
        FieldSchema(name="page_num", dtype=DataType.INT64),
        FieldSchema(name="content", dtype=DataType.VARCHAR, max_length=65535),
        FieldSchema(name="embedding", dtype=DataType.FLOAT_VECTOR, dim=1024),
    ]

    schema = CollectionSchema(fields=fields)

    # Create collection
    milvus_client.create_collection(
        collection_name=COLLECTION_NAME,
        schema=schema,
    )

    # Create index for vector search
    index_params = milvus_client.prepare_index_params()
    index_params.add_index(
        field_name="embedding",
        index_type="IVF_FLAT",  # Index type for approximate nearest neighbor search
        metric_type="COSINE",  # Similarity metric
        params={"nlist": 128},  # Number of clusters
    )

    milvus_client.create_index(
        collection_name=COLLECTION_NAME, index_params=index_params
    )

    print(f"Collection '{COLLECTION_NAME}' created successfully with index.")


setup_milvus_collection()

Collection 'document_ocr' already exists.

核心功能

让我们来实现文档理解系统的核心功能：

# Generate embeddings using Mistral
def generate_embedding(text):
    """Generate embedding for text using Mistral embedding model."""
    response = client.embeddings.create(model=embedding_model, inputs=[text])
    return response.data[0].embedding


# Store OCR results in Milvus
def store_ocr_in_milvus(url, ocr_result):
    """Process OCR results and store in Milvus."""
    # Extract pages from OCR result
    pages = []
    current_page = ""
    page_num = 0

    for line in ocr_result.split("\n"):
        if line.startswith("### Page "):
            if current_page:
                pages.append((page_num, current_page.strip()))
            page_num = int(line.replace("### Page ", ""))
            current_page = ""
        else:
            current_page += line + "\n"

    # Add the last page
    if current_page:
        pages.append((page_num, current_page.strip()))

    # Prepare data for Milvus
    entities = []
    for page_num, content in pages:
        # Generate embedding for the page content
        embedding = generate_embedding(content)

        # Create entity
        entity = {
            "url": url,
            "page_num": page_num,
            "content": content,
            "embedding": embedding,
        }
        entities.append(entity)

    # Insert into Milvus
    if entities:
        milvus_client.insert(collection_name=COLLECTION_NAME, data=entities)
        print(f"Stored {len(entities)} pages from {url} in Milvus.")

    return len(entities)


# Define OCR function
def perform_ocr(url):
    """Apply OCR to a URL (PDF or image)."""
    try:
        # Try PDF OCR first
        response = client.ocr.process(
            model=ocr_model, document={"type": "document_url", "document_url": url}
        )
    except Exception:
        try:
            # If PDF OCR fails, try Image OCR
            response = client.ocr.process(
                model=ocr_model, document={"type": "image_url", "image_url": url}
            )
        except Exception as e:
            return str(e)  # Return error message

    # Format the OCR results
    ocr_result = "\n\n".join(
        [
            f"### Page {i + 1}\n{response.pages[i].markdown}"
            for i in range(len(response.pages))
        ]
    )

    # Store in Milvus
    store_ocr_in_milvus(url, ocr_result)

    return ocr_result


# Process URLs
def process_document(url):
    """Process a document URL and return its contents."""
    print(f"Processing document: {url}")
    ocr_result = perform_ocr(url)
    return ocr_result

搜索功能

现在，让我们来实现搜索功能，以检索相关文档内容：

def search_documents(query, limit=5):
    """Search Milvus for similar content to the query."""
    # Check if collection exists
    if not milvus_client.has_collection(COLLECTION_NAME):
        return "No documents have been processed yet."

    # Load collection if not already loaded
    if milvus_client.get_load_state(COLLECTION_NAME) != LoadState.Loaded:
        milvus_client.load_collection(COLLECTION_NAME)

    print(f"Searching for: {query}")
    query_embedding = generate_embedding(query)

    search_params = {"metric_type": "COSINE", "params": {"nprobe": 10}}

    search_results = milvus_client.search(
        collection_name=COLLECTION_NAME,
        data=[query_embedding],
        anns_field="embedding",
        search_params=search_params,
        limit=limit,
        output_fields=["url", "page_num", "content"],
    )

    results = []

    if not search_results or not search_results[0]:
        return "No matching documents found."

    for i, hit in enumerate(search_results[0]):
        url = hit["entity"]["url"]
        page_num = hit["entity"]["page_num"]
        content = hit["entity"]["content"]
        score = hit["distance"]

        results.append(
            {
                "rank": i + 1,
                "score": score,
                "url": url,
                "page": page_num,
                "content": content[:500] + "..." if len(content) > 500 else content,
            }
        )

    return results


# Get statistics about stored documents
def get_document_stats():
    """Get statistics about documents stored in Milvus."""
    if not milvus_client.has_collection(COLLECTION_NAME):
        return "No documents have been processed yet."

    # Get collection stats
    stats = milvus_client.get_collection_stats(COLLECTION_NAME)
    row_count = stats["row_count"]

    # Get unique URLs
    results = milvus_client.query(
        collection_name=COLLECTION_NAME, filter="", output_fields=["url"], limit=10000
    )

    unique_urls = set()
    for result in results:
        unique_urls.add(result["url"])

    return {
        "total_pages": row_count,
        "unique_documents": len(unique_urls),
        "documents": list(unique_urls),
    }

演示：处理文档

让我们处理一些示例文档。您可以用自己的文档替换这些 URL。

# Example PDF URL (Mistral AI paper)
pdf_url = "https://arxiv.org/pdf/2310.06825.pdf"

# Process the document
ocr_result = process_document(pdf_url)

# Display a preview of the OCR result
print("\nOCR Result Preview:")
print("====================")
print(ocr_result[:1000] + "...")

Processing document: https://arxiv.org/pdf/2310.06825.pdf
Stored 9 pages from https://arxiv.org/pdf/2310.06825.pdf in Milvus.

OCR Result Preview:
====================
### Page 1
# Mistral 7B

Albert Q. Jiang, Alexandre Sablayrolles, Arthur Mensch, Chris Bamford, Devendra Singh Chaplot, Diego de las Casas, Florian Bressand, Gianna Lengyel, Guillaume Lample, Lucile Saulnier, Lélio Renard Lavaud, Marie-Anne Lachaux, Pierre Stock, Teven Le Scao, Thibaut Lavril, Thomas Wang, Timothée Lacroix, William El Sayed

![img-0.jpeg](img-0.jpeg)


#### Abstract

We introduce Mistral 7B, a 7-billion-parameter language model engineered for superior performance and efficiency. Mistral 7B outperforms the best open 13B model (Llama 2) across all evaluated benchmarks, and the best released 34B model (Llama 1) in reasoning, mathematics, and code generation. Our model leverages grouped-query attention (GQA) for faster inference, coupled with sliding window attention (SWA) to effectively handle sequences of arbitrary length with a reduced inference cost. We also provide a model fine-tuned to follow instructions, Mistral 7B - Instruct, that surpasses Llama 2 13B - chat mod...

我们也来处理一张图片：

# Example image URL (replace with your own)
image_url = "https://s3.eu-central-1.amazonaws.com/readcoop.cis.public-assets.prod/hero/old-german-scripts.png"

# Process the image
try:
    ocr_result = process_document(image_url)
    print("\nImage OCR Result:")
    print("=================")
    print(ocr_result)
except Exception as e:
    print(f"Error processing image: {e}")

Processing document: https://s3.eu-central-1.amazonaws.com/readcoop.cis.public-assets.prod/hero/old-german-scripts.png
Stored 1 pages from https://s3.eu-central-1.amazonaws.com/readcoop.cis.public-assets.prod/hero/old-german-scripts.png in Milvus.

Image OCR Result:
=================
### Page 1
![img-0.jpeg](img-0.jpeg)
![img-1.jpeg](img-1.jpeg)
![img-2.jpeg](img-2.jpeg)
![img-3.jpeg](img-3.jpeg)
![img-4.jpeg](img-4.jpeg)
![img-5.jpeg](img-5.jpeg)
![img-6.jpeg](img-6.jpeg)
![img-7.jpeg](img-7.jpeg)
![img-8.jpeg](img-8.jpeg)
![img-9.jpeg](img-9.jpeg)
![img-10.jpeg](img-10.jpeg)
![img-11.jpeg](img-11.jpeg)
![img-12.jpeg](img-12.jpeg)
![img-13.jpeg](img-13.jpeg)
![img-14.jpeg](img-14.jpeg)
![img-15.jpeg](img-15.jpeg)
![img-16.jpeg](img-16.jpeg)
![img-17.jpeg](img-17.jpeg)
![img-18.jpeg](img-18.jpeg)
![img-19.jpeg](img-19.jpeg)
![img-20.jpeg](img-20.jpeg)
![img-21.jpeg](img-21.jpeg)
![img-22.jpeg](img-22.jpeg)
![img-23.jpeg](img-23.jpeg)
![img-24.jpeg](img-24.jpeg)
![img-25.jpeg](img-25.jpeg)
![img-26.jpeg](img-26.jpeg)
![img-27.jpeg](img-27.jpeg)
![img-28.jpeg](img-28.jpeg)
![img-29.jpeg](img-29.jpeg)
![img-30.jpeg](img-30.jpeg)

演示：搜索文档

现在我们已经处理了一些文档，让我们来搜索它们：

# Get document statistics
stats = get_document_stats()
print(f"Total pages stored: {stats['total_pages']}")
print(f"Unique documents: {stats['unique_documents']}")
print("\nProcessed documents:")
for i, url in enumerate(stats["documents"]):
    print(f"{i + 1}. {url}")

Total pages stored: 58
Unique documents: 3

Processed documents:
1. https://arxiv.org/pdf/2310.06825.pdf
2. https://s3.eu-central-1.amazonaws.com/readcoop.cis.public-assets.prod/hero/old-german-scripts.png
3. https://arxiv.org/pdf/2410.07073

# Search for information
query = "What is Mistral 7B?"
results = search_documents(query, limit=3)

print(f"Search results for: '{query}'\n")

if isinstance(results, str):
    print(results)
else:
    for result in results:
        print(f"Result {result['rank']} (Score: {result['score']:.2f})")
        print(f"Source: {result['url']} (Page {result['page']})")
        print(f"Content: {result['content']}\n")

Searching for: What is Mistral 7B?
Search results for: 'What is Mistral 7B?'

Result 1 (Score: 0.83)
Source: https://arxiv.org/pdf/2310.06825.pdf (Page 2)
Content: Mistral 7B is released under the Apache 2.0 license. This release is accompanied by a reference implementation ${ }^{1}$ facilitating easy deployment either locally or on cloud platforms such as AWS, GCP, or Azure using the vLLM [17] inference server and SkyPilot ${ }^{2}$. Integration with Hugging Face ${ }^{3}$ is also streamlined for easier integration. Moreover, Mistral 7B is crafted for ease of fine-tuning across a myriad of tasks. As a demonstration of its adaptability and superior perform...

Result 2 (Score: 0.83)
Source: https://arxiv.org/pdf/2310.06825.pdf (Page 2)
Content: Mistral 7B is released under the Apache 2.0 license. This release is accompanied by a reference implementation ${ }^{1}$ facilitating easy deployment either locally or on cloud platforms such as AWS, GCP, or Azure using the vLLM [17] inference server and SkyPilot ${ }^{2}$. Integration with Hugging Face ${ }^{3}$ is also streamlined for easier integration. Moreover, Mistral 7B is crafted for ease of fine-tuning across a myriad of tasks. As a demonstration of its adaptability and superior perform...

Result 3 (Score: 0.82)
Source: https://arxiv.org/pdf/2310.06825.pdf (Page 1)
Content: # Mistral 7B

Albert Q. Jiang, Alexandre Sablayrolles, Arthur Mensch, Chris Bamford, Devendra Singh Chaplot, Diego de las Casas, Florian Bressand, Gianna Lengyel, Guillaume Lample, Lucile Saulnier, Lélio Renard Lavaud, Marie-Anne Lachaux, Pierre Stock, Teven Le Scao, Thibaut Lavril, Thomas Wang, Timothée Lacroix, William El Sayed

![img-0.jpeg](img-0.jpeg)


#### Abstract

We introduce Mistral 7B, a 7-billion-parameter language model engineered for superior performance and efficiency. Mistral 7...

尝试另一个搜索查询：

# Search for more specific information
query = "What are the capabilities of Mistral's language models?"
results = search_documents(query, limit=3)

print(f"Search results for: '{query}'\n")

if isinstance(results, str):
    print(results)
else:
    for result in results:
        print(f"Result {result['rank']} (Score: {result['score']:.2f})")
        print(f"Source: {result['url']} (Page {result['page']})")
        print(f"Content: {result['content']}\n")

Searching for: What are the capabilities of Mistral's language models?
Search results for: 'What are the capabilities of Mistral's language models?'

Result 1 (Score: 0.85)
Source: https://arxiv.org/pdf/2310.06825.pdf (Page 2)
Content: Mistral 7B is released under the Apache 2.0 license. This release is accompanied by a reference implementation ${ }^{1}$ facilitating easy deployment either locally or on cloud platforms such as AWS, GCP, or Azure using the vLLM [17] inference server and SkyPilot ${ }^{2}$. Integration with Hugging Face ${ }^{3}$ is also streamlined for easier integration. Moreover, Mistral 7B is crafted for ease of fine-tuning across a myriad of tasks. As a demonstration of its adaptability and superior perform...

Result 2 (Score: 0.85)
Source: https://arxiv.org/pdf/2310.06825.pdf (Page 2)
Content: Mistral 7B is released under the Apache 2.0 license. This release is accompanied by a reference implementation ${ }^{1}$ facilitating easy deployment either locally or on cloud platforms such as AWS, GCP, or Azure using the vLLM [17] inference server and SkyPilot ${ }^{2}$. Integration with Hugging Face ${ }^{3}$ is also streamlined for easier integration. Moreover, Mistral 7B is crafted for ease of fine-tuning across a myriad of tasks. As a demonstration of its adaptability and superior perform...

Result 3 (Score: 0.84)
Source: https://arxiv.org/pdf/2310.06825.pdf (Page 6)
Content: | Model | Answer |
| :--: | :--: |
| Mistral 7B - Instruct with Mistral system prompt | To kill a Linux process, you can use the `kill' command followed by the process ID (PID) of the process you want to terminate. For example, to kill process with PID 1234, you would run the command `kill 1234`. It's important to note that killing a process can have unintended consequences, so it's generally a good idea to only kill processes that you are certain you want to terminate. Additionally, it's genera...

结论

在本教程中，我们使用 Mistral OCR 和 Milvus 构建了一个完整的文档理解系统。这个系统可以

1. 处理来自 URL 的文档
2. 使用 Mistral 的 OCR 功能提取文本
3. 为内容生成向量 Embeddings
4. 在 Milvus 中存储文本和向量
5. 在所有处理过的文档中进行语义搜索

这种方法实现了强大的文档理解能力，超越了简单的关键字匹配，使用户能够根据意义而不是精确的文本匹配来查找信息。
