如何使用swagger

m0_63834575

370人浏览 · 2025-08-04 12:23:41

m0_63834575 · 2025-08-04 12:23:41 发布

springboot版本为2.1.×和2.7×的均可行

摘要: 原创出处 http://www.iocoder.cn/Spring-Boot/Swagger/ 「芋道源码」,相关代码还参考了苍穹外卖项目，实现的swagger的ui界面和苍穹外卖的一致。
pom.xlm文件依赖配置如下：

           <!-- Knife4j 增强版 (依赖 Swagger 2.x) -->
            <dependency>
                <groupId>com.github.xiaoymin</groupId>
                <artifactId>knife4j-spring-boot-starter</artifactId>
                <version>2.0.4</version> <!-- 与 Spring Boot 2.1.x 兼容 -->
            </dependency>

            <!-- Swagger 2.x 核心依赖 (与 Knife4j 2.0.4 匹配) -->
            <dependency>
                <groupId>io.springfox</groupId>
                <artifactId>springfox-swagger2</artifactId>
                <version>2.9.2</version>
            </dependency>

            <dependency>
                <groupId>io.springfox</groupId>
                <artifactId>springfox-swagger-ui</artifactId>
                <version>2.9.2</version>
            </dependency>

配置类config文件代码如下：注意要加注解@EnableSwagger2

package cn.iocoder.springboot.lab24.apidoc.config;

import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.web.servlet.config.annotation.InterceptorRegistry;
import org.springframework.web.servlet.config.annotation.ResourceHandlerRegistry;
import org.springframework.web.servlet.config.annotation.WebMvcConfigurationSupport;
import springfox.documentation.builders.ApiInfoBuilder;
import springfox.documentation.builders.PathSelectors;
import springfox.documentation.builders.RequestHandlerSelectors;
import springfox.documentation.service.ApiInfo;
import springfox.documentation.service.Contact;
import springfox.documentation.spi.DocumentationType;
import springfox.documentation.spring.web.plugins.Docket;
import springfox.documentation.swagger2.annotations.EnableSwagger2; // 正确的包路径



@Configuration
@EnableSwagger2 // 启用 Swagger 2.x
public class SwaggerConfiguration extends WebMvcConfigurationSupport {

    /**
     * 通过knife4j生成接口文档
     * @return
     */
    @Bean
    public Docket docket() {
        ApiInfo apiInfo = new ApiInfoBuilder()
                .title("测试接口文档示例")
                .version("2.0")
                .description("我是一段描述")
                .build();
        Docket docket = new Docket(DocumentationType.SWAGGER_2)
                .apiInfo(apiInfo)
                .select()
                .apis(RequestHandlerSelectors.basePackage("cn.iocoder.springboot.lab24.apidoc.controller"))
                .paths(PathSelectors.any())
                .build();
        return docket;
    }
    /**
     * 设置静态资源映射
     * @param registry
     */
    @Override
    protected void addResourceHandlers(ResourceHandlerRegistry registry) {
        registry.addResourceHandler("/doc.html").addResourceLocations("classpath:/META-INF/resources/");
        registry.addResourceHandler("/webjars/**").addResourceLocations("classpath:/META-INF/resources/webjars/");
    }

}

在controller类中的用法：注意注解的使用即可（@Api、@ApiOperation、@ApiImplicitParam）

package cn.iocoder.springboot.lab24.apidoc.controller;

import cn.iocoder.springboot.lab24.apidoc.dto.UserAddDTO;
import cn.iocoder.springboot.lab24.apidoc.dto.UserUpdateDTO;
import cn.iocoder.springboot.lab24.apidoc.vo.UserVO;
import io.swagger.annotations.Api;
import io.swagger.annotations.ApiImplicitParam;
import io.swagger.annotations.ApiOperation;
import org.springframework.web.bind.annotation.*;

import java.util.ArrayList;
import java.util.List;
import java.util.UUID;

@RestController
@RequestMapping("/users")
@Api(tags = "用户 API 接口")
public class UserController {

    @GetMapping("/list")
    @ApiOperation(value = "查询用户列表", notes = "目前仅仅是作为测试，所以返回用户全列表")
    public List<UserVO> list() {
        // 查询列表
        List<UserVO> result = new ArrayList<>();
        result.add(new UserVO().setId(1).setUsername("yudaoyuanma"));
        result.add(new UserVO().setId(2).setUsername("woshiyutou"));
        result.add(new UserVO().setId(3).setUsername("chifanshuijiao"));
        // 返回列表
        return result;
    }

    @GetMapping("/get")
    @ApiOperation("获得指定用户编号的用户")
    @ApiImplicitParam(name = "id", value = "用户编号", paramType = "query", dataTypeClass = Integer.class, required = true, example = "1024")
    public UserVO get(@RequestParam("id") Integer id) {
        // 查询并返回用户
        return new UserVO().setId(id).setUsername(UUID.randomUUID().toString());
    }

    @PostMapping("add")
    @ApiOperation("添加用户")
    public Integer add(UserAddDTO addDTO) {
        // 插入用户记录，返回编号
        Integer returnId = UUID.randomUUID().hashCode();
        // 返回用户编号
        return returnId;
    }

    @PostMapping("/update")
    @ApiOperation("更新指定用户编号的用户")
    public Boolean update(UserUpdateDTO updateDTO) {
        // 更新用户记录
        Boolean success = true;
        // 返回更新是否成功
        return success;
    }

    @PostMapping("/delete")
    @ApiOperation(value = "删除指定用户编号的用户")
    @ApiImplicitParam(name = "id", value = "用户编号", paramType = "query", dataTypeClass = Integer.class, required = true, example = "1024")
    public Boolean delete(@RequestParam("id") Integer id) {
        // 删除用户记录
        Boolean success = false;
        // 返回是否更新成功
        return success;
    }

}

VO类的用法：(@ApiModel、@ApiModelProperty )
创建 Application.java 类，配置 @SpringBootApplication 注解即可。
@ApiModel 注解，添加在 POJO 类，声明 POJO 类的信息。而在 Swagger 中，把这种 POJO 类称为 Model 类。（登录时的VO和DTO涉及ApiModel）
@ApiModelProperty 注解，添加在 Model 类的成员变量上，声明每个成员变量的信息。

package cn.iocoder.springboot.lab24.apidoc.vo;

import io.swagger.annotations.ApiModel;
import io.swagger.annotations.ApiModelProperty;

@ApiModel("用户 VO")
public class UserVO {

    @ApiModelProperty(value = "用户编号", required = true, example = "1024")
    private Integer id;
    @ApiModelProperty(value = "账号", required = true, example = "yudaoyuanma")
    private String username;

    public Integer getId() {
        return id;
    }

    public UserVO setId(Integer id) {
        this.id = id;
        return this;
    }

    public String getUsername() {
        return username;
    }

    public UserVO setUsername(String username) {
        this.username = username;
        return this;
    }

}

DTO类的使用：

package cn.iocoder.springboot.lab24.apidoc.dto;

import io.swagger.annotations.ApiModel;
import io.swagger.annotations.ApiModelProperty;

@ApiModel("用户添加 DTO")
public class UserAddDTO {

    @ApiModelProperty(value = "账号", required = true, example = "yudaoyuanma")
    private String username;
    @ApiModelProperty(value = "密码", required = true, example = "nicai")
    private String password;

    public String getUsername() {
        return username;
    }

    public UserAddDTO setUsername(String username) {
        this.username = username;
        return this;
    }

    public String getPassword() {
        return password;
    }

    public UserAddDTO setPassword(String password) {
        this.password = password;
        return this;
    }

}
